vi
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS N3150I-C or N3050I-C motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shields
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
N3150I-C / N3050I-C specications summary
CPU
N3150I-C: Intel
®
Celeron
®
Quad-core
Processor N3150 (Code Name:
Braswell)
N3050I-C: Intel
®
Celeron
®
Dual-core
Processor N3050 (Code Name:
Braswell)
Memory
2 x U-DIMM DDR3 1600/1066 MHz, Max 8GB, non-ECC, un-buffered
memory
Dual-channel memory architecture
* Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
Graphics Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: HDMI, D-Sub, LVDS
- Supports HDMI with max. resolution of 3840 x 2160 @30Hz
- Supports D-sub with max. resolution of 1920 x 1200 @60Hz
- Supports LVDS with max. resolution of 1920 x 1200 @60Hz
- Maximum shared memory of 512MB
* With DX11.1, OGL 4.2 support
** Support H.264, MPEG2, MVC, VC-1, WMV9, and VP8 decode
acceleration
Expansion slots
1 x PCI Express x4 slot (@x1 mode)
1 x Mini PCI Express slot (Half-length)
Storage
2 x SATA 6.0Gb/s connectors
LAN
Realtek
®
RTL8111H Gigabit LAN controller
Audio
Realtek
®
ALC887 8-channel High Denition Audio CODEC
- Supports Jack-Detection, and Front Panel Jack-Retasking
* Use a chassis with HD audio module in the front panel to support an
8-channel audio output.
USB
4 x USB 3.0/2.0 ports (2 at mid-board, 2 at back panel)
4 x USB 2.0/1.1 ports (2 at mid-board, 2 at back panel)
