vii
(continued on the next page)
ASUS Unique
Features
ASUS Exclusive Features
- ASUS Anti-surge Protection
- ASUS AI Suite 3
- ASUS USB 3.0 Boost
ASUS Quiet Thermal Solution
- ASUS Fan Xpert
- Fanless Heatsink Design
ASUS EZ DIY
- ASUS UEFI BIOS
- ASUS MyLogo 2
- ASUS EZ-Flash 2
- ASUS Crash Free BIOS3
100% All High-quality Conductive Polymer Capacitors
Back Panel I/O Ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x HDMI port
1 x D-Sub port
1 x COM port
2 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
1 x Gigabit LAN (RJ-45) port
3 x Audio jacks support 8-channel audio output
Internal I/O
Connectors
1 x USB 2.0/1.1 connectors support additional 2 USB 2.0/1.1 ports
1 x USB 3.0/2.0 connectors support additional 2 USB 3.0/2.0 ports
2 x SATA 6.0Gb/s connectors
1 x Chassis fan connector
1 x CPU fan connector
1 x Chassis intrusion connector
1 x Front panel audio connector
1 x COM connector
1 x LPT connector
1 x TPM connector
1 x 24-pin EATX power connector
1 x 4-pin EATX 12V power connector
1 x Buzzer
1 x LVDS connector
1 x System panel connector
BIOS features 64Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0,SM BIOS 2.7,
ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree
BIOS 3, My Favorites, Quick Note, Last Modied log, F12 PrintScreen,
F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect)
memory information
Manageability
Wfm 2.0, DMI 2.0, WOL by PME, PXE
Operating System
Support
Windows
®
8.1 64-bit, Window
®
7 64-bit
N3150I-C / N3050I-C specications summary
