PPM Conguration

This item allows you to manage and congure the CPU’s power.

EIST [Enabled]

Allows you to enable or disable Enhanced Intel

SpeedStep Technology (EIST).

[Disabled] The CPU runs at its default speed.

[Enabled] The operating system controls the CPU speed.

Turbo Mode [Enabled]

This item allows you to automatically set the CPU cores to run faster than the base

operating frequency when it is below the operating power, current and temperature

specication limit. Conguration options: [Enabled] [Disabled]

CPU C state Report [Auto]

This item allows you to set the power saving of the CPU states. Conguration options:

[Auto] [Disabled] [Enabled]

The following item appears only when you set the CPU C state Report item to [Enabled]

or [Disabled].

Max CPU C-state [C7]

This item allows you to set the maximum C‑state that the processor supports.

Conguration options: [C7] [C6] [C1]

2.5.3 SoC Conguration

Intel IGD Conguration

IGD Turbo [Auto]

Allows you to enable/disable IGD Turbo. Conguration options: [Auto] [Enabled]

[Disabled]

Primary Display [Auto]

Select which IGD/PCI Graphics device should be used as Primary Display.

Conguration options: [Auto] [IGD] [PCIe]

iGPU Memory [64M]

Allows you to select the amount of system memory allocated to DVMT 5.0 used by the

iGPU. Conguration options: [32M] [64M] [96M] [128M] ~ [480M] [512M]

LVDS Conguration

IGD Flat Panel [Disabled]

Allows you to enable or disable IGD video output to onboard LVDS. Conguration

options: [Disabled] [LVDS]

All-in-One Chassis [None]

Set up this item for simplied Aio conguration. Conguration options: [None] [ECS

(21.5\x22)] [Mitac Maestro (21.5\x22)] [Gigabyte (18.5\x22)] [LP‑215x (21.5\x22)]

[Wibtek A21 (21.5\x22)] [Wibtek A23 (23.6\x22)] [Jumper Sail (21.5\x22)] [Pixxo HP‑

A206D (21.5\x22)] [22AM33NB (21.5\x22)] [3N0D (21.5\x22)]

ASUS N3150I-C / N3050I-C 2-15
