ASUS M5A97 LE R2.0
2-5
Chapter 2
3
2.1.3 CPU heatsink and fan assembly installation
Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the
heatsink and fan if necessary.
++E8047_M5A97_LE_R2.0_V2.indb 5 8/1/13 3:51:14 PM
