Adaptec asr-81605zq sgl [105/116] Adaptec raid 6405t led connector specification
![Adaptec asr-81605zq sgl [105/116] Adaptec raid 6405t led connector specification](/views2/1163701/page105/bg69.png)
DescriptionSignalJ1 Pin Number
LED CathodeACTIVITY2
LED Anode+3.3V1
• Adaptec RAID 6805E/6805E R5 External Alarm Connector: Molex 22-28-4023 or equivalent
• Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
DescriptionSignalJ12 Pin Number
Open collector transistor~2kHz Square Wave2
—+3.3V1
Adaptec RAID 6405T LED Connector Specication
ASR-6405T SGL2272700-R
• Adaptec RAID 6405T Activity LED Header Connector: Molex 22-43-6030 or equivalent
• Activity LED Header Mating Cable Connector: Molex 22-55-2161 or equivalent
J2:
22-55-2161 Pin
Number
DescriptionSignalJ2 Pin Number
2LED Anode+3.3V1
1LED CathodeACTIVITY CN0, LANE 02
4LED Anode+3.3V3
3LED CathodeACTIVITY CN0, LANE 14
6LED Anode+3.3V5
5LED CathodeACTIVITY CN0, LANE 26
8LED Anode+3.3V7
7LED CathodeACTIVITY CN0, LANE 38
• Adaptec RAID 6405T Aggregate Activity LED Board Connector: Molex 22-28-4023 or equivalent
• Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J1:
DescriptionSignalJ1 Pin Number
LED CathodeACTIVITY2
LED Anode+3.3V1
• Adaptec RAID 6405T External Alarm Connector: Molex 22-28-4023 or equivalent
• Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
DescriptionSignalJ12 Pin Number
Open collector transistor~2kHz Square Wave2
—+3.3V1
105Proprietary and Condential to PMC-Sierra, Inc., and for its customers.
Document No.: CDP-00310-01-A Rev. A, Issue
Serial Attached SCSI RAID Controllers Installation and User's Guide
