12 | English
2 609 007 727 | (13.11.13) Bosch Power Tools
To ensure optimum dust extraction, pay attention that the
punched holes in the sanding sheet match with the holes in
the sanding plate.
The sanding plate 3 is fitted with Velcro backing for quick and
easy fastening of sanding sheets with Velcro adhesion.
Before attaching the sanding sheet 4, free the Velcro backing
of the sanding plate 3 from any debris by tapping against it in
order to enable optimum adhesion.
The machine is fitted with 2 sanding sheets that can be
changed individually, depending on the degree of wear.
Only use the machine when both sanding sheets are
mounted.
Only use sanding sheets with the same grain size.
Position the sanding sheet 4 flush alongside one edge of the
sanding plate 3, then lay the sanding sheet onto the sanding
plate and press firmly.
To remove the sanding sheet 4, grasp it at one of the tips and
pull it off from the sanding plate 3.
Sanding sheets of the Bosch Delta Sander can be used.
Sanding accessories, such as fleece pads/polishing cloth
pads, are attached to the sanding plate in the same manner.
Selecting the Sanding Sheet
Depending on the material to be worked and the required rate
of material removal, different sanding sheets are available:
For reworking or polishing, especially of metal and stone, use
fleece/polishing cloth pad.
Depending on the desired surface quality of the workpiece,
different fleece types or polishing cloth pads are to be used.
Operation
Starting Operation
Observe correct mains voltage! The voltage of the pow-
er source must agree with the voltage specified on the
nameplate of the machine. Power tools marked with
230 V can also be operated with 220 V.
Switching On and Off
To start the machine, push the ON/Off switch 1 downward to
position “1”.
To switch off the machine, push the On/Off switch 1 upward
to positon “0”.
To save energy, only switch the power tool on when using it.
Working Advice
Before any work on the machine itself, pull the mains
plug.
Wait until the machine has come to a standstill before
placing it down.
The removal capacity during sanding is mainly determined by
the selection of the sanding sheet.
Only flawless sanding sheets achieve good sanding capacity
and extend the service life of the machine.
Pay attention to apply uniform sanding pressure; this increas-
es the working life of the sanding sheets.
Intensifiying the sanding pressure does not lead to an in-
crease of the sanding capacity, but to increased wear of the
machine and the sanding sheet.
For precise on-the-spot sanding of edges, corners and hard to
reach areas, it is also possible to work only with the tip or an
edge of the sanding plate.
A sanding sheet that has been used for metal should not be
used for other materials.
Use only original Bosch sanding accessories.
Maintenance and Service
Maintenance and Cleaning
Before any work on the machine itself, pull the mains
plug.
For safe and proper working, always keep the machine
and ventilation slots clean.
If the replacement of the supply cord is necessary, this has to
be done by Bosch or an authorized Bosch service agent in or-
der to avoid a safety hazard.
After-sales Service and Application Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions
concerning our products and their accessories.
In all correspondence and spare parts order, please always in-
clude the 10-digit article number given on the type plate of
the machine.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: (0844) 7360109
Fax: (0844) 7360146
E-Mail: boschservicecentre@bosch.com
Grain size
For the working of all types of materi-
als such as wood, paint, filler, lacquer,
hard and soft wood as well as chip-
boards and metal.
40–180
For coarse-sanding, e. g. of rough,
unplaned beams and boards
coarse 40
For face sanding and planing small ir-
regularities
medium 80, 120
For finish and fine sanding of hard
woods
fine 180
