22 | English

1 609 92A 0LG | (28.4.14) Bosch Power Tools

Briefly press the measuring button

to initiate the measurement. Then the laser beam

is switched off. To switch the laser beam on again, briefly press the measuring button

To initiate a further measurement, briefly press the measuring button

again.

 Do not point the laser beam at persons or animals and do not look into the la-

ser beam yourself, not even from a large distance.

Note: The measured value typically appears within 0.5 seconds and no later than

4 seconds. The duration of the measurement depends on the distance, the lighting

conditions and the reflective properties of the target surface. Upon completion of the

measurement the laser beam is automatically switched off.

Auto-Sum (see figure B)

The auto-sum automatically shows the sum of all individual measurements (e.g. use-

ful for the material calculation).

The auto-sum value is erased as soon as the device is switched off or if it automatically

switches off when no button is pressed after 5 minutes.

The auto-sum is not saved. A subsequent correction of the auto-sum is not possible.

Aim the laser beam at the target surface.

Briefly press the measuring button

to initiate the measurement.

The current measured value

appears in the bottom line of the dis-

play. The laser beam is switched off.

To switch on the laser beam, briefly press the measuring button

again. The current measured value

is displayed in the bottom line.

The previous measured value

is displayed in the middle line. In the

top line, the auto-sum

(the sum of the current and previous meas-

ured value) is displayed.

Switching the Sound On and Off (3 601 K72 5..)

Switch the measuring tool off.

Press and hold the measuring button

. When the cursor

is on the desired setting, release the measuring button

. After releasing, the measuring tool switches itself on

with the selected setting.
