![Bosch glm 30 [9/18] Operation](/views2/1164726/page9/bg9.png)
English | 21
Bosch Power Tools 1 609 92A 0LG | (28.4.14)
When the battery symbol appears for the first time on the display, at least 100
individual measurements are still possible.
When the battery symbol flashes, the batteries/rechargeable batteries must be
replaced. Measurements are no longer possible.
Always replace all batteries/rechargeable batteries at the same time. Do not use
different brands or types of batteries/rechargeable batteries together.
Remove the batteries/rechargeable batteries from the measuring tool when not
using it for longer periods.
When storing for longer periods, the batteries/recharge-
able batteries can corrode and self-discharge.
Operation
Initial Operation
Do not leave the switched-on measuring tool unattended and switch the mea-
suring tool off after use.
Other persons could be blinded by the laser beam.
Protect the measuring tool against moisture and direct sun light.
Do not subject the measuring tool to extreme temperatures or variations in tem-
perature.
As an example, do not leave it in vehicles for a long time. In case of large
variations in temperature, allow the measuring tool to adjust to the ambient temper-
ature before putting it into operation. In case of extreme temperatures or variations
in temperature, the accuracy of the measuring tool can be impaired.
Avoid heavy impact to or falling down of the measuring tool. After severe exte-
rior effects to the measuring tool, it is recommended to carry out an accuracy
check (see “
Accuracy Check of the Distance Measurement
”, page
24
) each time be-
fore continuing to work.
Switching On and Off
To switch on the measuring tool, briefly press the measuring button
2
. Measuring tool
and laser are switched on.
Do not leave the switched-on measuring tool unattended and switch the mea-
suring tool off after use.
Other persons could be blinded by the laser beam.
To
switch off
the measuring tool, press the measuring button
2
and hold it down.
Measuring Procedure (see figure A)
Once switched on, the measuring tool is in the length measurement mode.
The rear edge of the measuring tool is always the reference level for the measurement.
Place the measuring tool against the desired starting point of the measurement (e.g.
a wall).
