English | 19
Bosch Power Tools 1 609 92A 0LG | (28.4.14)
Laser beam diameter (at 25 °C)
approx.
–at 10m distance
–at 30m distance
9mm
C)
27 mm
C)
9mm
C)
27 mm
C)
Automatic switch-off after approx.
–Laser
–Measuring tool
(without measurement)
20 s
5min
20 s
5min
Weight according to
EPTA-Procedure 01/2003
0.1 kg 0.1 kg
Dimensions
105 x 41 x 24 mm 105 x 41 x 24 mm
Degree of protection
IP 54 (dust and splash
proof)
D)
IP 54 (dust and splash
proof)
D)
Batteries
Rechargeable batteries
2 x 1.5 V LR03 (AAA)
2 x 1.2 V HR03 (AAA)
2 x 1.5 V LR03 (AAA)
2 x 1.2 V HR03 (AAA)
Individual measurement per
battery set
5000 5000
Setting the unit of measure
–
Setting the sound
–
A) For measurements from the rear measuring tool edge, weak backlighting and 25 °C operating tem-
perature are applicable for high reflectivity of the target (e.g. a white-painted wall). In addition, a devi-
ation influence of ± 0.05 mm/m must be taken into account.
B) For measurements from the rear measuring tool edge, strong backlighting and – 10 °C to +45 °C
operating temperature are applicable for low reflectivity of the target (e.g. a black box). In addition, a
deviation influence of ±0.15 mm/m must be taken into account.
C) At 25 °C operating temperature
D) except battery compartment
The measuring tool can be clearly identified with the serial number
5
on the type plate.
Digital Laser Measure GLM 30
