20 | English
1 609 92A 0LG | (28.4.14) Bosch Power Tools
Product Features
The numbering of the product features shown refers to the illustration of the
measuring tool on the graphic page.
1
Display
2
Measuring button
3
Battery lid
4
Latch of battery lid
5
Serial number
6
Laser warning label
7
Reception lens
8
Laser beam outlet
9
Laser target plate*
10
Laser viewing glasses*
11
Protective pouch*
* The accessories illustrated or described are not included as standard delivery.
Display Elements
a
Auto-sum
b
Previous measuring value
c
Current measuring value
d
Laser, switched on
e
Length measurement
f
Battery low indicator
g
Temperature warning
h
Error message
“Error”
Assembly
Inserting/Replacing the Batteries
Using alkali-manganese or rechargeable batteries is recommended for operation of
the measuring tool.
With 1.2-V-rechargeable batteries fewer measurements could be possible than with
1.5-V-batteries.
To open the battery lid
3
, press the latch
4
and remove the battery lid. Insert the batteries/
rechargeable batteries. When inserting, pay attention to the correct polarity according
to the representation on the inside of the battery compartment.
OBJ_BUCH-2004-004.book Page 20 Monday, April 28, 2014 11:36 AM
