.Connecting to Power (Power Supply)

The chassis ships with only one power supply, and a second

power supply option is at your discretion. When the chassis is

equipped with two power supplies, you can have the following

advanced performance.

♦ Hot Swappable –

The design of the power system is based on an idea of providing

maximum flexibility and redundancy. In this way, you may remove any of

the two power supplies without turning off the system.

♦ Redundancy –

During operation, both power supplies are switched on and share the

current load. In case that one of them should fail, the other will

instantaneously take 100% of the load without any loss. Similarly, if one

power supply is removed from servicing, it can be switched off and

removed while the chassis continues functioning.

♦ Protection System –

The power of each converter bay comes from the two shared

power supplies. Each bay is isolated from each other under a

certain protection mechanism, so that it is free from any

problem that might occur to the power supplies or faulty

converter bay. This is the best solution to protect your

investment in media converters.

There is an optional solution for the backup power, -

48 volt DC to DC Power Supply.

The chassis system is equipped with one power supply and

allows one additional power supply for redundancy. For reliable

operation, we suggest that you run the chassis system with two

power supplies are in place.

Attention!
