12
UNDERSTANDING LED INDICATORS
The front panel LEDs provide instant status feedback, and, helps monitor and
troubleshoot when needed.
Front Panel
There is an array of LED indicators, which provides you with
instant feedback on the status of the power and the fan.
DMC-1000
Power and Fan LED
1 / 2 Indicates which the power (fan) is working, depends on
where the power supply was installed at the rear.
On (Green) Power supply feed in Power LED
Off No power supply feeding
On (Amber) Faulty power supply Power Fail
LED
Off Power supply works normally
On (Amber) Faulty Fan Fan Fail LED
Off Fan works normally
