D-Link DMC-1000 [4/14] Media converter chassis system
![D-Link DMC-1000 [4/14] Media converter chassis system](/views2/1166205/page4/bg4.png)
4
19” Media Converter Chassis System
The chassis equipped with two power supplies and sixteen media
converters
The chassis system ships with only one power supply.
Proprietary media converters and a second power supply are not
included!
Attention!
