UNPACKING AND INSTALLATION
This chapter provides unpacking and installation information for the Switch.
To avoid causing any damage to the Switch, we recommend that you read
this chapter carefully before starting installation.
Unpacking
When unpacking the product package, you shall find these items listed
below.
¾ 19” Media Converter Chassis System
¾ One power supply installed on the chassis
¾ One AC power cord
¾ User’s Manual
¾ Accessories: rackmount screws (8 pcs) & rackmount ears
(2 pcs) rubber foot (4 pcs)
If any item is found missing or damaged, please contact your local reseller
for replacement.
Installation
The site where you place the chassis system may greatly affect its
performance. When installing, take the following into your consideration:
As with any electric device, you should place the equipment where it will not
be subjected to extreme temperatures, humidity, or electromagnetic
interference. Specifically, the site you select should meet the following
requirements:
- The ambient temperature should be between 32 and 104
