16 | Setting Up the Monitor
4 Insert the two tabs on the upper part of the stand in the slots on the back of
the monitor till it snaps into its place.
Place the monitor upright.
1 Slide one hand in the cutout area on the bottom cushion and use the other
hand to hold the stand.
2 Lift the monitor carefully to prevent it from slipping or falling.
3 Remove the cover from the monitor.
CAUTION: Do not press on the panel screen when lifting the monitor.
