![Dell e2016h [9/42] Preset display modes](/views2/1166613/page9/bg9.png)
About Your Monitor | 9
Faceplate coating AG type, hard-coating 3H
Backlight LED
Response time 6ms Typ. g-to-g with OD (Fast mode)
Color depth 16.7 million colors
Color gamut (typical) 72%* (CIE1931)
*Color gamut (typical) is based on CIE1976 (85%) and CIE1931 (72%) test standards.
Resolution Specifications
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz (automatic)
Maximum preset resolution 1440x900 at 60 Hz
Video display capabilities 480i, 576i, 480p, 576p, 720p
Preset Display Modes
Display Mode Horizontal
Frequency
(kHz)
Vertical
Frequency (Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/
Vertical)
720 x 400 31.47 70 28.32 -/+
640 x 480 31.47 60 25.18 -/-
640 x 480 37.50 75 31.50 -/-
800 x 600 37.88 60 40 +/+
800 x 600 46.88 75 49.50 +/+
1024 x 768 48.36 60 65 -/-
1024 x 768 60.02 75 78.75 +/+
1152 x 864 67.50 75 108 +/+
1280 x 1024 64 60 108 +/+
1280 x 1024 80 75 135 +/+
1280 x 800 49.70 60 83.50 -/+
1440 x 900 55.94 60 106.50 -/+
1440 x 900 70.60 75 136.75 -/+
