Foxconn nt-a3800 [11/33] Fit the nanopc into the vesa mount with power button locating at the top for easy touch
![Foxconn nt-a3800 [11/33] Fit the nanopc into the vesa mount with power button locating at the top for easy touch](/views2/1167510/page11/bgb.png)
2
6
2.2. Fit the NanoPC into the Vesa Mount with power button locating at the top for easy touch.
Lift up the NanoPC straightly to take it out.
CAUTION
!
2
1
