Boot
Version 2.15.1231. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Main Advanced Boot Security Save & Exit
Boot
Boot Configuration
Bootup Numlock State [On]
Quiet Boot [Disabled]
Fast Boot [Enabled]
Lanch CSM [Enabled]
Lanch LAN OpROM policy [Do not launch]
Built-in EFI Shell Support [Disabled]
Boot Option Priorities
→ ← : Select Screen
↑ ↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Select the keyboard Numlock state
► Bootup Numlock State
This item is used to select the keyboard numlock state. The defaulte setting is [On].
► Quiet Boot
This item is used to enable or disable the quiet boot.
[Disabled] : Displays the normal POST messages.
[Enabled] : Displays OEM customer logo instead of POST messages.
► Fast Boot
This item is used to enable or disable boot with initialization of a minimal set of devices required
to launch active boot option. This is no effect for BBS boot options.
► Launch CSM
This item controls if CSM will be launched.
► Launch LAN OpROM policy
This item controls the execution of UEFI and Legacy PXE OpROM.
► Built-in EFI Shell Support
This item is used to control whether the “Built-in EFI Shell” appears in the Boot Option.
You can set the “Built-in EFI Shell” option boot priority in “Boot Option Priorities” listing when
this item is set to [Enabled].
► Boot Option Priorities
These items are used to set the system boot order.
