RJ-45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describes the states of the LAN port LEDs.

USB 3.0/2.0 Port

The USB 3.0 port supports the USB 3.0 specication and is compatible to the USB 2.0/1.1 specication.

Use this port for USB devices such as a USB keyboard/mouse, USB printer, USB ash drive and etc.

Line In Jack (Blue)

The default line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

LineOutJack(Green)

The default line out jack. Use this audio jack for a headphone or 2-channel speaker. This jack can be used

to connect front speakers in a 4/5.1/7.1-channel audio conguration.

Mic In Jack (Pink)

The default Mic in jack. Microphones must be connected to this jack.

B. Playback of Blu-ray Disc

™

In order to get better playback quality, when playing the Blu-ray Disc

™

, refer to the recommended system

requirements (or better) below.

• AMD A series processors

• Memory: Two 1 GB DDR3 1333 MHz memory modules with dual channel mode enabled

• BIOS Setup: At least 512 MB of UMA Frame Buffer Size (refer to Chapter 2, "BIOS Setup," "Peripherals\

GFX Conguration," for more information)

• Playback software: CyberLink PowerDVD 10.0 or later (Note: Please ensure Hardware Acceleration

is enabled. Whether Hardware Acceleration can be enabled for 3D Blu-ray discs is dependent on the

APU being used.)

• HDCP compliant monitor(s)

To congure 7.1-channel audio, you have to use an HD front panel audio module and enable the

multi-channel audio feature through the audio driver.

Activity LED

Connection/

Speed LED

LAN Port

Activity LED:Connection/Speed LED:

State Description

Orange 1 Gbps data rate

Green 100 Mbps data rate

Off 10 Mbps data rate

State Description

Blinking Data transmission or receiving is occurring

Off No data transmission or receiving is occurring
