- 4 -
GA-B85M-DS3H-A Motherboard Layout
KB_MS_USB
CPU_FAN
SYS_FAN
LGA1150
ATX
GA-B85M-DS3H-A
F_AUDIO
AUDIO
M_BIOS
DDR3_4
DDR3_3
DDR3_2
DDR3_1
BAT
F_PANEL
ATX_12V_2X4
Intel
®
B85
3 2
1
0
5 4
F_USB30
R_USB30
CODEC
CLR_CMOS
B_BIOS
VGA_DVI
USB_LAN
PCIEX16
PCIEX1_1
PCIEX1_2
F_USB1F_USB2
LPT
COM
HDMI
Realtek
®
GbE LAN
iTE
®
Super I/O
SATA3
SATA3
SATA2
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-B85M-DS3H-A motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
