9) BAT (Battery)

 Thebatteryprovidespowertokeepthevalues(suchasBIOScongurations,date,andtimeinformation)

in the CMOS when the computer is turned off. Replace the battery when the battery voltage drops to a low

level, or the CMOS values may not be accurate or may be lost.

10) F_PANEL (Front Panel Header)

Connect the power switch, reset switch, and system status indicator on the chassis to this header according

to the pin assignments below. Note the positive and negative pins before connecting the cables.

PLED-

PW-

PLED+

PW+

HD-

RES+

HD+

RES-

Power Switch

Hard Drive

Activity LED

Reset Switch

Power LED

The front panel design may differ by chassis. A front panel module mainly consists of power switch, reset switch,

power LED, hard drive activity LED and etc. When connecting your chassis front panel module to this header, make

sure the wire assignments and the pin assignments are matched correctly.

• PW (Power Switch, Red):

 Connectstothepowerswitchonthechassisfrontpanel.Youmaycongurethewaytoturnoffyour

system using the power switch (refer to Chapter 2, "BIOS Setup," "Power Management," for more

information).

• HD (Hard Drive Activity LED, Blue):

Connects to the hard drive activity LED on the chassis front panel. The LED is on when the hard drive

is reading or writing data.

• RES (Reset Switch, Green):

Connects to the reset switch on the chassis front panel. Press the reset switch to restart the computer

if the computer freezes and fails to perform a normal restart.

• NC (Purple):

No connection.

• PLED (Power LED, Yellow):

Connects to the power status indicator on the chassis front panel. The LED

is on when the system is operating. The LED is off when the system is in S3/

S4 sleep state or powered off (S5).

System Status LED

S0 On

S3/S4/S5 Off

You may clear the CMOS values by removing the battery cable:

1. Turn off your computer and unplug the power cord.

2. Unplug the the battery cable from the battery cable header and wait for one minute.

3. Plug in the battery cable.

4. Plug in the power cord and restart your computer.

• Always turn off your computer and unplug the power cord before replacing the battery.

• Replace the battery with an equivalent one. Danger of explosion if the battery is replaced with

an incorrect model.

• Contact the place of purchase or local dealer if you are not able to replace the battery by yourself

or uncertain about the battery model.

• When installing the battery, note the orientation of the positive side (+) and the negative side (-)

of the battery (the positive side should face up).

• Used batteries must be handled in accordance with local environmental regulations.
