1-2 ProductSpecications
CPU Built in with an Intel
®
Quad-Core Celeron
®
N3150 SoC (1.6 GHz)
* Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage
to these components.
2 MB Cache
Memory 2 x DDR3 DIMM sockets supporting up to 8 GB of system memory
* If only one memory is to be installed, be sure to install it in the DDR3_1 slot.
Dual channel memory architecture
Support for DDR3/DDR3L 1600/1333 MHz memory modules
* Due to an SoC limitation, if a 1333 MHz memory is installed, it will be downgraded
to 1066 MHz.
Support for non-ECC memory modules
Onboard
Graphics
Integrated in the SoC:
- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
- 1 x HDMI port, supporting a maximum resolution of 3840x2160@30 Hz
* Support for HDMI 1.4 version.
Support for up to 3 displays at the same time
Maximum shared memory of 512 MB
Audio
Realtek
®
ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module
and enable the multi-channel audio feature through the audio driver.
LAN Realtek
®
GbE LAN chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x1
1 x
M.2 Socket 1 connector for the wireless communication module (optional)
(M2_WIFI)
Storage Interface SoC:
- 2 x SATA 6Gb/s connectors (SATA 3 0/1)
ASMedia
®
ASM1061 chip:
- 2 x SATA 6Gb/s connectors (SATA 3 2/3)
USB SoC:
- 4 x USB 3.0/2.0 port (2 ports on the back panel, 2 ports available through
the internal USB header)
2 x GL850S USB 2.0 Hubs:
- 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin AT
X 12V power connector
1 x CPU fan header
1 x system fan header
4 x SATA
6Gb/s connectors
1 x front panel header
1 x front panel audio header
