(Note) The DVI-D port does not support D-Sub connection by adapter.

• After installing the HDMI device, make sure to set the default sound playback device to HDMI.

(The item name may differ depending on your operating system.)

• Tosetupatriple-displayconguration,youmustinstallmotherboarddriversintheoperating

systemrst.

DVI-D Port

(Note)

TheDVI-DportconformstotheDVI-Dspecicationandsupportsamaximumresolutionof1920x1200@60Hz

(the actual resolutions supported depend on the monitor being used). Connect a monitor that supports DVI-D

Master Audio formats. It also supports up to 192KHz/16bit 8-channel LPCM audio

output. You can use this port to connect your HDMI-supported monitor. The maximum supported resolution

is 3840x2160@30 Hz, but the actual resolutions supported are dependent on the monitor being used.

RJ-45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describes the states of the LAN port LEDs.

USB 2.0/1.1 Port

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.

Line In (Blue)

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

multi-channel audio feature through the audio driver. Please visit GIGABYTE's website for more

software information.

Activity LED

Connection/

State Description

Orange 1 Gbps data rate

Green 100 Mbps data rate

device and then remove it from the motherboard.

an electrical short inside the cable connector.

- 9 -
