• The front panel audio header supports HD audio by default.

• Audio signals will be present on both of the front and back panel audio connections simultaneously.

• Some chassis provide a front panel audio module that has separated connectors on each wire instead

of a single plug. For information about connecting the front panel audio module that has different

wire assignments, please contact the chassis manufacturer.

11) F_AUDIO (Front Panel Audio Header)

The front panel audio header supports Intel

®

HighDenitionaudio(HD)andAC'97audio.Youmayconnect

your chassis front panel audio module to this header. Make sure the wire assignments of the module

1

12) TPM (Trusted Platform Module Header)

You may connect a TPM (Trusted Platform Module) to this header.

Pin No. Denition Pin No. Denition

13) COMA/COMB (Serial Port Headers)

The COM header can provide one serial port via an optional COM port cable. For purchasing the optional

COM port cable, please contact the local dealer.

1

2
