ES1100 Series User’s Guide 23
CHAPTER 4
Product Specifications
These are the product specifications.
Table 6 Product Specifications
Dimension ES1100-8P/16P: 262mm(W) x 184mm(D) x 41mm(H)
ES1100-16: 216 mm (W) x 133 mm (D) x 42 mm (H)
ES1100-24: 441 mm (W) x 131 mm (D) x 44 mm (H)
ES1100-24E: 267 mm (W) x 162 mm (D) x 42 mm (H)
Weight ES1100-8P: 1.4 kg
ES1100-16: 0.8 kg
ES1100-16P: 1.7 kg
ES1100-24: 1.5 kg
ES1100-24E: 1.3 kg
Standard IEEE802.3 10 BASE-T
IEEE802.3u 100 BASE-TX
IEEE802.3x full-duplex flow control
IEEE802.3az (EEE) (ES1100-16/24/24E only)
IEEE 802.1p Class of Service
IEEE 802.3af PoE standard (ES1000-8P and ES1100-16P)
Interface ES1100-8P: 8 x 10/100 Mbps auto MDI/MDI-X RJ-45 switching port (including 4 FE PoE ports)
ES1100-16P: 16 x 10/100 Mbps auto MDI/MDI-X RJ-45 switch port (including 8 FE PoE ports)
ES1100-16: 16 x 10/100 Mbps auto MDI/MDI-X RJ-45 switching ports
ES1100-24/24E: 24 x 10/100 Mbps auto MDI/MDI-X RJ-45 switching ports
Cable
Connections
RJ-45 (10 BASE-T): Category 3,4,5 UTP/STP
RJ-45 (100 BASE-TX): Category 5 UTP/STP
Network Data
Rate
10/100 Mbps Auto-negotiation
Transmission
Mode
10/100 Mbps: Full-duplex, Half-duplex
Data Forwarding
Rate
14880 pps for 10 Base-T
148800 pps for 100 Base-Tx
LED Indications System: PWR
Ports: LINK/ACT
PoE ports: PoE (for ES1100-8P/16P)
