![Zyxel ES-3124PWR [127/250] Mstp commands](/views2/1168512/page127/bg7f.png)
Ethernet Switch CLI Reference Guide
127
CHAPTER 37
MSTP Commands
Use these commands to configure Multiple Spanning Tree Protocol (MSTP) as defined in
IEEE 802.1s.
37.1 Command Summary
The following section lists the commands for this feature.
Table 85 mstp Command Summary
COMMAND DESCRIPTION M P
show mstp Displays MSTP configuration for the Switch. E 3
spanning-tree mode <RSTP|MRSTP|MSTP> Specifies the STP mode you want to implement on
the Switch.
C13
mstp Activates MSTP on the Switch. C 13
no mstp Disables MSTP on the Switch. C 13
mstp configuration-name <name> Sets a name for an MSTP region.
name: 1-32 printable characters
C13
mstp revision <0-65535> Sets the revision number for this MST Region
configuration.
C13
mstp hello-time <1-10> maximum-age <6-
40> forward-delay <4-30>
Sets Hello Time, Maximum Age and Forward Delay.
hello-time: The time interval in seconds between
BPDU (Bridge Protocol Data Units) configuration
message generations by the root switch.
maximum-age: The maximum time (in seconds) the
Switch can wait without receiving a BPDU before
attempting to reconfigure.
forward-delay: The maximum time (in seconds)
the Switch will wait before changing states.
C13
mstp max-hop <1-255> Sets the maximum hop value before BPDUs are
discarded in the MST Region.
C13
Table 86 mstp instance Command Summary
COMMAND DESCRIPTION M P
show mstp instance <0-16> Displays MSTP instance configuration. E 3
no mstp instance <0-16> Disables the specified MST instance on the Switch. C 13
mstp instance <0-16> priority <0-
61440>
Specifies the bridge priority of the instance.
priority: Must be a multiple of 4096.
C13
mstp instance <0-16> vlan <vlan-list> Specifies the VLANs that belongs to the instance. C 13
