Zyxel ES-3124PWR [152/250] This example enables port security on port 1 and limits the number of learned mac addresses to 5

Chapter 44 Port Security Commands

Ethernet Switch CLI Reference Guide

152

44.2 Command Examples

This example enables port security on port 1 and limits the number of learned MAC addresses

to 5.

sysname# configure

sysname(config)# port-security

sysname(config)# port-security 1

sysname(config)# no port-security 1 learn inactive

sysname(config)# port-security 1 address-limit 5

sysname(config)# exit

sysname# show port-security 1

Port Security Active : YES

Port Active Address Learning Limited Number of Learned MAC Address

01 Y Y 5
