Chapter 4 AAA Commands
Ethernet Switch CLI Reference Guide
28
no aaa accounting commands Disables accounting of command sessions on the Switch. C 13
show aaa accounting dot1x Displays accounting settings for recording IEEE 802.1x
session events.
E3
aaa accounting dot1x <start-
stop|stop-only>
<radius|tacacs+> [broadcast]
Enables accounting of IEEE 802.1x authentication sessions
and specifies the mode and protocol method. Optionally,
sends accounting information for IEEE 802.1x authentication
sessions to all configured accounting servers at the same
time.
C13
no aaa accounting dot1x Disables accounting of IEEE 802.1x authentication sessions
on the Switch.
C13
show aaa accounting exec Displays accounting settings for recording administrative
sessions via SSH, Telnet or the console port.
E3
aaa accounting exec <start-
stop|stop-only>
<radius|tacacs+> [broadcast]
Enables accounting of administrative sessions via SSH,
Telnet and console port and specifies the mode and protocol
method. Optionally, sends accounting information for
administrative sessions via SSH, Telnet and console port to
all configured accounting servers at the same time.
C13
no aaa accounting exec Disables accounting of administrative sessions via SSH,
Telnet or console on the Switch.
C13
show aaa accounting system Displays accounting settings for recording system events, for
example system shut down, start up, accounting enabled or
accounting disabled.
E3
aaa accounting system
<radius|tacacs+> [broadcast]
Enables accounting of system events and specifies the
protocol method. Optionally, sends accounting information for
system events to all configured accounting servers at the
same time.
C13
no aaa accounting system Disables accounting of system events on the Switch. C 13
Table 10 Command Summary: aaa accounting (continued)
COMMAND DESCRIPTION M P
