Chapter 60 Trunk Commands
Ethernet Switch CLI Reference Guide
194
60.2 Command Examples
This example activates trunk 1 and places ports 5-8 in the trunk using static link aggregation.
This example disables trunk one (T1) and removes ports 1, 3, 4, and 5 from trunk two (T2).
This example looks at the current trunks.
The following table describes the labels in this screen.
sysname(config)# trunk t1
sysname(config)# trunk t1 interface 5-8
sysname(config)# no trunk T1
sysname(config)# no trunk T3 lacp
sysname(config)# no trunk T2 interface 1,3-5
sysname# show trunk
Group ID 1: inactive
Status: -
Member number: 0
Group ID 2: inactive
Status: -
Member number: 0
Group ID 3: inactive
Status: -
Member number: 0
Table 129 show trunk
LABEL DESCRIPTION
Group ID This field displays the trunk ID number and the current status.
inactive: This trunk is disabled.
active: This trunk is enabled.
Status This field displays how the ports were added to the trunk.
-: The trunk is disabled.
Static: The ports are static members of the trunk.
LACP: The ports joined the trunk via LACP.
Member Number This field shows the number of ports in the trunk.
Member This field is displayed if there are ports in the trunk.
This field displays the member port(s) in the trunk.
