Справочник командного интерфейса Страница: 47

Zyxel ES-3124PWR [47/250] Command examples

Chapter 9 Classifier Commands

Ethernet Switch CLI Reference Guide

9.2 Command Examples

This example creates a classifier for packets with a VLAN ID of 3. The resulting traffic flow is

identified by the name VLAN3. The policy command can use the name VLAN3 to apply

policy rules to this traffic flow.

sysname# config

sysname(config)# classifier VLAN3 vlan 3

sysname(config)# exit

sysname# show classifier

Index Active Name Rule

1 Yes VLAN3 VLAN = 3;
