Heyner capsula multifix aero [10/24] Heyner capsula multi aero heyner capsula multi aero are equipped with only one head cushion

English

www.heyner-germany.de www.heyner-germany.de

A - Headrest

A1 - Head cushion

A2 - Reduction cushion (only ERGO-Line)

B - Shoulder pads

BL - Base holes

BT - Base part

C - Buckle latches

D - Buckle

E - Seat cover

F - Adjuster cover

FG - Installation manual storage

G - Belt system

G1 - Belt slots

G2 - Harness belts

G3 - Waist belt

G4 - Buckle belt

G5 - Central harness belt

GK - Belt clip

GN - Belt lugs

GR - Belt guide

GII - Belt guide gr. II (15-25kg)

GIII - Belt guide gr. III (22-36 kg)

H - Positioning handle headrest

GV - Harness adjuster

J - Belt guide hole

L - Case for instruction manual

N - Backrest

O - Fabric cover

P - Shock minimizer

PG - Positioning handle

R - Belt anchorage

S - Installation sticker

SB - Safety bolt

SG - Connector belts

SR - Sicherungsriegel

ST - Seat part

TT - Top Tether

U - Diagonal belt of the three-point-

vehicle-belt

V - Buckle latch of the three-point-

vehicle-belt

VH - Connecting hook

W - Lap belt of the three-point-

vehicle-belt

X - belt buckle of the three-point-

vehicle-belt

I - ISOFIX

IA - ISOFIX-anchors

IE - ISOFIX-ﬁ xing lever

IH - ISOFIX-installation aids

IK - ISOFIX-terminals

IM - ISOFIX-arms

IT - ISOFIX-release buttons

Index / page

1. Age Group I (9 kg to 18 kg Y) S. 16

1.1 Use

HEYNER® Capsula MultiFix ERGO 3D/HEYNER® Capsula Multi ERGO 3D/

HEYNER® Capsula MultiFix AERO / HEYNER® Capsula Multi AERO

as child car seat

S. 16

1.2 Adjusting to the size of the child S. 16

1.3 Fixing with ISOFIX and Top Tether

HEYNER® Capsula MultiFix ERGO 3D/HEYNER® Capsula MultiFix AERO

S. 17

1.4 Fixing with the three-point belt of your car

HEYNER® Capsula Multi ERGO 3D/HEYNER® Capsula Multi AERO

S. 19

1.5 The child in the

HEYNER® Capsula MultiFix ERGO 3D/HEYNER® Capsula Multi ERGO 3D/HEYNER® Capsula MultiFix AERO

HEYNER® Capsula Multi AERO

S. 21

1.6 Release of ISOFIX and Top Tether / expansion

S. 22

2. Age Group II+III (15-36 kg)

S. 23

2.1 Preparation of the seat / Expansion of the ﬁ ve-point belt system of the seat

S. 23

2.2 Installation / Fixing with ISOFIX (WITHOUT Top Tether)

S. 23

2.3 Installation / Positioning

HEYNER® Capsula Multi ERGO 3D/HEYNER® Capsula Multi AERO

S. 25

2.4 Adjustment of the headrest to the size of your child

S. 25

3. Care instructions

S. 26

4. Important notices

S. 27

5. Some ﬁ nal hints

S. 28

1 Age Group I (9 kg to 18 kg Y)

1.1 Use HEYNER ® Capsula MultiFix ERGO 3D /

HEYNER ® Capsula Multi ERGO 3D /

HEYNER ® Capsula MultiFix AERO

HEYNER ® Capsula Multi-AERO as child car seat

Thank you for choosing this

HEYNER® Capsula child car seat

HEYNER® Capsula child car seat to secure your child in the car.

HEYNER ® Capsula child car seats

HEYNER ® Capsula child car seats are available

• as

MultiFix

: using with ISOFIX and Top Tether or

•

Multi

: Fixing with the three-point belt of the car

Please check before use, if your car is approved with ISOFOX anchors (IA) and Top Tether (TT)

for this seat! Optimum safety features of this seat can only be brought into effect, if it is used

properly.

Therefore, ensure the correct installation in the car and read the instruction manual.

The installation must be performed only by adults!

1.2. Adjusting to the size of the child

1.2.1. Preparation

The

HEYNER ® Capsula MultiFix ERGO 3D

HEYNER ® Capsula MultiFix ERGO 3D and

HEYNER ® Capsula Multi ERGO 3D

HEYNER ® Capsula Multi ERGO 3D carry a head

cushion (A1) and a reduction cushion (A2) (the

HEYNER ® Capsula MultiFix AERO /

HEYNER ® Capsula Multi AERO

HEYNER ® Capsula Multi AERO are equipped with only one head cushion).

The cushions are provided for the special protection of young children weighing 9kg - 18kg.

We recommend removing this only when the child is too big for it,

at least if the child weighs 18 kg
