GRILLCHEF

Assembly step 8

• Position the lid (1) on the re bowl (13) so that both

lid hinges (3) interlock with the re bowl hinges (11).

•

• Insert one bolt (25) through each drill hole on the lid

and re bowl hinges.

•

• Secure both bolts (25) by inserting the straight shaft

of the spring split pin (26) through the hole at the end

of the bolt. Ensure that it is securely in place.

• Carefully and slowly open and close the lid.

• If you detect some resistance, do not force the lid as

this could damage the hinges. The cause of the re-

sistance should be remedied immediately.

Assembly step 9

• Insert the mounting plate for the fat catching tray (32)

from above through the small, oval opening in the re

bowl (13).

The bent clip on the mounting plate must be positi-

oned centrally underneath the small, round opening

in the re bowl (13).

• Hook the fat catching tray (15) into the holder from

underneath.

• Place the ame tamer (34) in the re bowl (13).

• Place the grill (8) in the re bowl (13).
