Landmann 12754 [23/32] Operation

GRILLCHEF

3. Store the pressure reducer (1) with the gas hose (3) underneath the barbecue. Make sure that the gas hose is not kinked

or twisted in any way.

4. Storing the gas cylinder correctly:

– Fit the gas cylinder valve with a cap nut and safety cap.

– Do not store the gas cylinder in rooms below ground level, or in or near stairways, hallways or passages and tho-

roughfares between buildings.

– Always store gas cylinders upright, even if they are empty!

Notes: The „Compact Quick-on“ is so designed as to prevent it from being tted to the valve, unless the regu-

lator handle is in the „o“ position; therefore, never attempt to Mount or to dismount it, when the handle is

not in that position.

Operation

Starting up the burner

Before using, wash the roasting tray (2) thoroughly with warm soapy water and allow both to dry well. Then apply

cooking oil to the top side of both parts. This will prevent the cooked food from sticking to the roasting tray.

1. Check to ensure that ....

– no ammable materials or substances are in close proximity to the cooker. Minimum distance to ammable mate-

rials or substances: 2m above and 1m to the side; distance to ame resistant materials or substances - min 0.25 m.

– the cooker is positioned rmly on a at, suciently large surface area. It must not be moved during operation.

2. Check to ensure that ....

– the burner is fully assembled and has no obvious defects.

– the roasting tray (2) is inserted.

Once the „Compact Quick-on“ is correctly mounted on

the valve, Gas supply is possible by turning the regulator

handle (5) upwards (counterclockwise). To shut o the

Gas supply, reverse above procedure; an arrow engraved

on the handle indicates the closing direction (g. No. 3).

Caution: If you are unable to turn the regulator handle to

the „on“ position, this means that your „Compact Quick-

on“ is not correctly connected to the valve. Do not force

the handle to open, and restart the operations described

under 3 above.

Caution: Do not lean over the cooker during steps 7 and 8. Keep a safe distance.

3. Open the cylinder valve by pulling the red safety catch on the control button (5) forwards a little and turning the control

button to the 12 o‘clock setting.

4. Check to make sure that the gas system is leak-proof. If not, immediately turn the control button (5) to the 3 o‘clock

setting.

5. Push down the middle hand control knob and keep pressing whilst turning anti-clockwise to the ”MAX” position (a
