8
11. Over-heat Monitoring Protection
The blade motor and each of the two wheel drive motors are monitored continuously during
operation for any situation that may cause these motors to over-heat. In such event, Robomow will
stop operation of at least that motor and possibly the mower itself and indicate that the motor is
cooling down. While unusual, this may happen when the mower is on grass that is severely
overgrown; the underside of the mower is clogged from poor cleaning maintenance; the mower has
encountered an obstacle that is unable to activate the bumper sensor preventing it from moving; or
a problem landscape area has caused the mower to get stuck and is preventing it from moving.
How It Works
A small wire, called the perimeter wire, is placed around the perimeter of the lawn and any other areas
where you do not want the mower to enter. A small signal is generated from a device attached to the
perimeter wire, called the Perimeter Switch. When turned on, this signal is carried through the perimeter
wire, creating what we define as a virtual wall. The virtual wall is visible only to Robomow, keeping
Robomow where you want it, on your lawn. The perimeter switch must be turned on to activate the
perimeter wire before Robomow will operate.
WARNING!
This warning symbol will be found at several
points throughout the pages of this manual.
It is intended to highlight an important safety,
warning or cautionary message.
Please pay particular attention to these
areas and be sure you fully understand
the message before proceeding.
Perimeter Switch
Virtual wall
