▶DRAM Timing Mode [Auto]

Selects the memory timing mode.

[Auto] DRAM timings will be determined based on SPD (Serial Presence Detect)

of installed memory modules.

[Link] Allows user to congure the DRAM timing manually for all memory

channel.

[UnLink] Allows user to congure the DRAM timing manually for respective

memory channel.

▶Advanced DRAM Conguration

Press <Enter> to enter the sub-menu. This sub-menu will be activated after setting [Link]

or [Unlink] in “DRAM Timing Mode”. User can set the memory timing for each memory

channel. The system may become unstable or unbootable after changing memory tim-

ing. If it occurs, please clear the CMOS data and restore the default settings. (Refer to

the Clear CMOS jumper/ button section to clear the CMOS data, and enter the BIOS to

load the default settings.

▶HT Link Speed

This item allows you to set the Hyper-Transport Link speed. Setting to [Auto], the sys-

tem will detect the HT link speed automatically.

▶Adjusted HT Link Frequency

It shows the adjusted HT Link frequency. Read-only.

▶HT Link Control

Press <Enter> to enter the sub-menu.

▶HT Incoming/ Outgoing Link Width

These items allow you to set the Hyper-Transport Link width. Setting to [Auto], the

system will detect the HT link width automatically.

▶Adjust PCI-E Frequency (MHz)

Sets the PCI Express frequency.

▶XXX Voltage [Auto] (optional)

Sets these voltages. If set to "Auto", BIOS will set these voltages automatically or you

can set it manually.

▶Spread Spectrum [Disabled]

This function reduces the EMI (Electromagnetic Interference) generated by modulating

clock generator pulses.

[Enabled] Enables the spread spectrum function to reduce the EMI (Electromagnetic

Interference) problem.

[Disabled] Enhances the overclocking ability of CPU Base clock.
