Содержание
- Angle grinder 1
- Szlifierka k towa 1
- Winkelschleifer 1
- Углошлифовальная машинка 1
- English 4
- Explanation of general view 4
- General safety rules 4
- Specifications 4
- Additional safety rules 5
- Assembly 6
- Functional description 6
- Installing or removing depressed center grinding wheel multi disc accessory fig 5 6
- Installing or removing wheel guard fig 4 6
- Installing side grip handle fig 3 6
- Save these instructions 6
- Shaft lock fig 1 6
- Switch action fig 2 6
- Accessories 7
- Grinding and sanding operation fig 7 7
- Maintenance 7
- Operation 7
- Replacing carbon brushes 7
- Super flange fig 6 7
- Allgemeine sicherheitsregeln 9
- Deutsch 9
- Erklärung der gesamtdarstellung 9
- Technische angaben 9
- Zusätzliche sicherheitsregeln 11
- Bedienung des schalters abb 2 12
- Betrieb 12
- Bewahren sie diese anweisungen sorgfältig auf 12
- Einsetzen des seitengriffs zusatzgriff abb 3 12
- Funktionsbeschreibung 12
- Montage 12
- Montage und demontage der schutzhaube abb 4 12
- Montieren und demontieren einer gekröpften trennschleifscheibe multischeibe sonderzubehör abb 5 12
- Spindel arretiertaste abb 1 12
- Super flansch abb 6 12
- Austausch der kohlebürsten 13
- Schleifen und schmirgeln abb 7 13
- Wartung 13
- Zubehör 13
- Dane techniczne 15
- Objasnienia do widoku ogólnego 15
- Ogólnezasady bezpieczenstwa 15
- Polski 15
- Blokada walu rys 1 17
- Dodatkowe zalecenia dotyczace bezpieczeñstwa 17
- Instrukcj obstugi nalezy zachowac 17
- Opis dzialania 17
- Mechanizm przelqcznika rys 2 18
- Montaz 18
- Montaz i demontaz tarczy o obnizonym srodku sciernicy lamelowej osprz t dodatkowy rys 5 18
- Montaz lub demontaz o stony tarczy rys 4 18
- Montaz uchwytu bocznego r kojesc rys 3 18
- Obstuga 18
- Super kolnierz rys 6 18
- Konserwacja 19
- Szlifowanie rys 7 19
- Wymiana szczotek w glowych 19
- Wyposazenie dodatkowe 19
- Общие правила техники безопасности 20
- Пояснения к общему виду 20
- Русский 20
- Технические характеристики 20
- Дополнительные правила техники безопасности 22
- Блокировка вала рис 1 23
- Быстрозажимной фланец рис 6 23
- Включение рис 2 23
- Описание функций 23
- Сборка 23
- Сохраните данные инструкции 23
- Установка боковой дополнительной ручки рис 3 23
- Установка или снятие ограждения диска рис 4 23
- Установка или снятие шлифовального диска с углубленным центром многофункционального диска принадлежность рис 5 23
- Замена угольных щеток 24
- Зачистка и шлифовка рис 7 24
- Обслуживание 24
- Принадлежности 24
- Эксплуатация 24
Похожие устройства
- Makita ga7050 Инструкция по эксплуатации
- Makita ga9050 Инструкция по эксплуатации
- Makita fs4300 Инструкция по эксплуатации
- Makita rp2300fc Инструкция по эксплуатации
- Makita dp4010 Инструкция по эксплуатации
- Makita ddf343rfe Инструкция по эксплуатации
- Makita ddf343she3 Инструкция по эксплуатации
- Makita td0101f Инструкция по эксплуатации
- Makita uc4030a/5m Инструкция по эксплуатации
- Makita uc4530a/5m Инструкция по эксплуатации
- Makita sk102z Инструкция по эксплуатации
- Cat Eye STEALTH 10 (CC-GL 10) Инструкция по эксплуатации
- Cat Eye V3 (CC-TR300TW) Инструкция по эксплуатации
- Makita ls1216 Инструкция по эксплуатации
- Makita hm0870c Инструкция по эксплуатации
- Cat Eye V3N (CC-TR210DW) Инструкция по эксплуатации
- Makita hm1101c Инструкция по эксплуатации
- Cat Eye STRADA DIGITAL WIRELESS (CC-RD410DW) Инструкция по эксплуатации
- Cat Eye Padrone (CC-PA100W) Инструкция по эксплуатации
- Cat Eye Micro Wireless (CC-MC100W) Инструкция по эксплуатации
ENGLISH Explanation of general view 1 2 3 4 5 6 Shaft lock Switch trigger Lock lever Wheel guard Screw Bearing box 7 8 9 10 11 12 Lock nut Depressed center wheel Super flange Inner flange Lock nut wrench Exhaust vent 13 14 15 16 17 18 Inhalation vent Commutator Insulating tip Carbon brush Brush holder cap Screwdriver SPECIFICATIONS Model GA7020 GA7020F GA7020S GA7020SF GA9020 GA9020F GA9020S GA9020SF Depressed center wheel diameter 180 mm 230 mm Spindle thread M14 M14 No load speed min 1 8 500 6 600 Overall length 473 mm 473 mm Net weight 4 7 kg Rated voltage 4 7 kg EMI Due to our continuing program of research and development the specifications herein are subject to change without notice Note Specifications may differ from country to country Symbols END202 2 The following show the symbols used for the tool Be sure that you understand their meaning before use Read instruction manual DOUBLE INSULATION Wear safety glasses For public low voltage distribution systems of between 220 V and 250 V Switching operations of electric apparatus cause voltage fluctuations The operation of this device under unfavor able mains conditions can have adverse effects to the operation of other equipment With a mains impedance equal or less than 0 27 Ohms it can be presumed that there will be no negative effects The mains socket used for this device must be protected with a fuse or protective circuit breaker having slow tripping characteristics GENERAL SAFETY RULES ENA001 2 Only for EU countries Do not dispose of electric equipment together with house hold waste material In observance of European Directive 2002 96 EC on waste electrical and electronic equipment and its imple mentation in accordance with national law electric equip ment that have reached the end of their life must be collected separately and returned to an environmentally compatible recycling facility Intended use The tool is intended for grinding sanding and cutting of metal and stone materials without the use of water Power supply The tool should be connected only to a power supply of the same voltage as indicated on the nameplate and can only be operated on single phase AC supply They are double insulated in accordance with European Standard and can therefore also be used from sockets without earth wire 4 WARNING When using electric tools basic safety precautions including the following should always be followed to reduce the risk of fire electric shock and personal injury Read all these instructions before operating this product and save these instructions For safe operations 1 Keep work area clean Cluttered areas and benches invite injuries 2 Consider work area environment Do not expose power tools to rain Do not use power tools in damp or wet locations Keep work area well lit Do not use power tools where there is risk to cause fire or explosion 3 Guard against electric shock Avoid body contact with earthed or grounded surfaces e g pipes radiators ranges refrigerators 4 Keep children away Do not let visitors touch the tool or extension cord All visitors should be kept away from work area 5 Store idle tools
