4
ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Intended use
ENE034-1
The tool is intended for drilling and screw driving in wood,
metal and plastic.
General Power Tool Safety
Warnings GEA010-1
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
CORDLESS DRIVER DRILL
SAFETY WARNINGS
GEB088-1
1. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
2. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting
accessory contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
3. Hold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring. Fasteners contacting a
“live” wire may make exposed metal parts of the
power tool “live” and could give the operator an
electric shock.
4. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
5. Hold the tool firmly.
6. Keep hands away from rotating parts.
7. Do not leave the tool running. Operate the tool
only when hand-held.
8. Do not touch the drill bit or the workpiece
immediately after operation; they may be
extremely hot and could burn your skin.
9. Some material contains chemicals which may be
toxic. Take caution to prevent dust inhalation and
skin contact. Follow material supplier safety data.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product (gained
from repeated use) replace strict adherence to safety
rules for the subject product. MISUSE or failure to
follow the safety rules stated in this instruction
manual may cause serious personal injury.
1. Red indicator
2. Button
3. Battery cartridge
4. Star marking
5. Battery capacity
6. Switch trigger
7. Lamp
8. Reversing switch lever
9. Speed change lever
10. Adjusting ring
11. Graduation
12. Arrow
13. Sleeve
14. Groove
15. Hook
16. Screw
17. Bit holder
18. Bit
Model DDF470 DDF480
Capacities
Steel 13 mm 13 mm
Wood 38 mm 38 mm
Wood screw 10 mm x 90 mm 10 mm x 90 mm
Machine screw M6 M6
No load speed (min
-1
)
High (2) 0 - 1,550 0 - 1,550
Low (1) 0 - 400 0 - 400
Overall length 185 mm 185 mm
Net weight 1.6 kg 1.5 kg 1.7 kg
Battery cartridge BL1430/BL1440
BL1815/BL1815N/
BL1820
BL1830/BL1840/
BL1850
Rated voltage D.C. 14.4 V D.C. 18 V
