ENGLISH en
11
6.8 Drill chuck with "Quick" change system
(for BS 18 Quick)
Removal: See page 2, fig. A. Push the interlocking
ring forward (a) and pull off the drill chuck (b).
Mounting: Push the interlock ring forward and
move the chuck as far as the limit stop on the drill
spindle.
6.9 Drill chuck (for BS 14.4, BS 18)
See page 2, fig. B.
Fitting: unscrew protective cap (13). Screw the
quick-clamping chuck onto the spindle thread. The
quick-clamping chuck can be tightened (and
released again) using an open-jawed spanner.
When working with long screw bits or bit holders, we
recommend the use of the bit clamping bush
6.31281 (see Accessories chapter).
Use only genuine Metabo accessories.
If you need any accessories, check with your
dealer.
For the dealer to select the correct accessory, he
needs to know the exact model designation of your
power tool.
See page 4.
A Quick clamping chuck.
Clamping, BS 14.4, BS 18:
unscrew protective
cap (13). Screw the quick-clamping chuck onto
the spindle thread. The quick-clamping chuck
can be tightened (and released again) using
an open-jawed spanner.
B Battery pack
C Angle screwdriver attachment.
D Battery charger
EBit clamping bush
FBit holder with Quick replacement system
GBit box
For the complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must ONLY be
carried out by qualified electricians!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Battery packs may not be disposed of with regular
waste. Return faulty or used battery packs to your
Metabo dealer!
Do not allow battery packs to come into contact with
water!
Protect the environment, and do not dispose
of power tools and battery packs with house-
hold waste. Observe national regulations on
separated collection and recycling of disused
machines, packaging and accessories.
Before disposal, discharge the battery pack in the
power tool. Prevent the contacts from short-
circuiting (e. g. by protecting them with adhesive
tape).
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
U = Voltage of battery pack
n = No-load speed
Tightening torque for screwing:
M
A
= soft screwing application (wood)
M
B
= hard screwing application (metal)
M
C
= adjustable torque (with torque control)
Max. drill diameter:
D
1 max
= in steel
D
2 max
= in softwood
m = weight (with battery pack)
G=spindle thread
Vibration total value (vector sum of three directions)
determined in accordance with EN 60745:
a
h, D
= Vibration emission value(drilling into
metal)
a
h, S
= Vibration emission value (screwing
without impact)
K
h, ...
= Uncertainty (vibration)
The vibration emission level given in this
information sheet has been measured in
accordance with a standardised test given in
EN 60745 and may be used to compare one tool
with another. It is also suitable for a provisional
estimate of the vibratory load.
The specified vibration level applies to the main
applications of the power tool. However, if the tool is
used for other applications, with different
accessories or is poorly maintained, the vibration
level may vary. This can considerably increase the
vibratory load over the entire working period.
An estimation of the level of exposure to vibration
should also take into account the times when the
tool is switched off or when it is running but not
actually doing the job. This can considerably reduce
the vibratory load over the entire working period.
Identify additional safety measures to protect the
operator from the effects of vibration such as:
maintain the tool and the accessories, keep the
hands warm, organisation of work patterns.
Typical A-effective perceived sound levels:
L
pA
=Sound-pressure level
7. Tips and Tricks
8. Accessories
9. Repairs
10. Environmental Protection
11. Technical Specifications
