User instructions
28
3.4 Using the baskets
The dishwasher has a capacity of
10 place-settings
, including serving dishes.
EN 50242 STANDARD LOADS FOR CERTIFICATION BODIES
LOWER BASKET UPPER BASKET
LOWER BASKET
The lower basket receives the full force of the lower spray arm, and should therefore be used for
the “toughest” items with a heavier degree of soiling.
All types and combinations of loads are permitted, provided that the
dishes, pots and pans are arranged with all the soiled surfaces
exposed to the water jets coming from the bottom.
With fixed supports
To make full use of the space in the basket when large dishes are
loaded, some models have tilting plate supports.
With tilting supports
LOADING THE LOWER BASKET
Carefully load flat plates, soup plates, dessert and serving dishes, positioning them vertically. Pots,
pans and their covers must be loaded upside down. When loading soup plates and dessert bowls,
be sure to leave a gap between them.
Loading examples:
