User instructions
30
LOADING THE UPPER BASKET
Load plates facing forward; cups, bowls etc. must always be facing downwards. The left side of the
basket can be loaded with cups and glasses on two levels. On the right plates and saucers can be
slotted verticalli into the forks.
Loading examples:
ADJUSTING THE UPPER BASKET
The upper basket can be adjusted in
two positions
, according to the user’s needs and according
to the height of the dishes in the lower basket.
Proceed as follows:
•
turn the retainer
E
on both runners, right and left, through
90°
;
•
remove the basket;
•
lift the basket and fit the smaller pairs of wheels in the runners;
•
return the retainers
E
to their original position.
