Smeg STA4645 [5/30] User instructions
![Smeg STA4645 [5/30] User instructions](/views2/1017935/page5/bg5.png)
User instructions
After using the table to identify the most appropriate washing program:
• press the
ON/OFF
button
(1)
and wait for the
PROGRAM
INDICATOR LIGHT
(2)
to illuminate;
• keep pressing the
PROGRAM SELECTION
button
(3)
until the
indicator light corresponding to the desired program illuminates;
• close the door; after about
2"
the program will start. While it is in
progress, the relative
LIGHT
will flash (indicating that the program is
being executed).
DURATION CONSUMPTION
PROGRAMME,
NUMBER & SYMBOL
LOAD CROCKERY
AND CUTLERY
PROGRAM
PROGRESS
MINUTES
(2)
WATER
LITRES (1)
POWER
KWh (2)
1
SOAK
Pans and dishes
awaiting
a further wash
Cold prewash
9' 5 0,03
2
LIGHT
Wash immediately
after use for dishes
with light dirt
Wash at 45°C
Cold rinse
Rinse at 68°C
Dry
59' 12 0,90
3
ECO (*)
EN 50242
Wash immediately
after use for dishes
with normal dirt
Wash at 55°C
Cold rinse
Rinse at 66°C
Dry
175' 13 1,01
4
Dishes
Cold prewash
Wash at 50°C
Wash at 65°C
Cold rinse
Dry
with normal dirt
Rinse at 70°C
(**) (**) (**)
5
INTENSIVE
Very dirty pans
and dishes (except
delicate items)
Prewash at 45°C
Wash at 70°C
2 cold rinses
Rinse at 70°C
Dry
105' 20 1,50
Only run the soak program with half loads.
(*) Reference program as per EN 50242 standard.
(**) When the "
AUTO 60-70" program is selected, the dishwasher recognises the type of dirt and
automatically adjusts the washing parameters as appropriate.
(1) Average power consumption with the softener set on level 2.
(2) The cycle duration and power consumption may vary according to the water and room
temperatures, and the type and amount of dishes.
AUTO 60-70
