User instructions
After using the table to identify the most appropriate washing program:
• press the
ON/OFF
button
(1)
and wait for the
PROGRAM
INDICATOR LIGHT (2)
to illuminate;
• keep pressing the
PROGRAM SELECTION
button
(3)
until the
indicator light corresponding to the desired program illuminates;
• close the door; after about
2"
the program will start. While it is in
progress, the relative
LIGHT
will flash (indicating that the program is
being executed).
DURATION CONSUMPTION
PROGRAMME,
NUMBER & SYMBOL
LOAD CROCKERY
AND CUTLERY
PROGRAM
PROGRESS
MINUTES
(2)
WATER
LITRES (1)
POWER
KWh (2)
1
SOAK
Pans and dishes
awaiting
a further wash
Cold prewash
9' 5 0,03
2
LIGHT
Wash immediately
after use for dishes
with light dirt
Wash at 45°C
Cold rinse
Rinse at 68°C
Dry
59' 12 0,90
3
ECO (*)
EN 50242
Wash immediately
after use for dishes
with normal dirt
Wash at 55°C
Cold rinse
Rinse at 65°C
Dry
175' 13 1,01
4
NORMAL
Dishes
with normal dirt
Cold prewash
Wash at 65°C
Cold rinse
Rinse at 68°C
Dry
80' 17 1,20
5
INTENSIVE
Very dirty pans and
dishes (except
delicate items)
Prewash at 45°C
Wash at 70°C
2 cold rinses
Rinse at 70°C
Dry
105' 20 1,50
Only
run the soak program with half loads.
(*) Reference program as per EN 50242 standard.
(1) Average power consumption with the softener set on
level 2
.
(2) The cycle duration and power consumption may vary according to the water and
room temperatures, and the type and amount of dishes.
