OVER-RUN TIMER

Case

ATTENTION: When the humidity rate is

above the selected value, the automatic

option takes precedence over the manual

and the unit cannot then be switched off

using a switch.

Maintenance

After Sales Service

This product controls automatically the

over-run time, which is proportional to the

time that has been needed to bring the

relative humidity level to the adjusted level,

depending on which the over-run will range

from 2 minutes to a maximum of 20

minutes.

1:Automatic operation (fig.9)

In automatic operation, the humidistat causes

the extractor to operate automatically when

the humidity level in the room is higher than

the pre-set level. The extractor will stop

automatically when the humidity drops below

the selected level and after the selected

period set on the over-run timer.

2: Automatic operation as in case (1)

but with the facility to override the humidistat

by means of the light switch (fig.8), when the

humidity level in the room is lower than the

selected level. In this case, the extractor

continues to operate for the selected period of

time (over-run timer) after the switch light has

been switched off.

- If the period of operation is less than 50

seconds then the over-run timer will not

operate.

- If the period of operation is more than 50

seconds then the over-run timer will operate

in accordance to the pre-set time period.

Models provided with a PIR (passive infra-

red) detector. The unit starts automatically

when a movement is detected with a

maximum distance of 4 metres (fig.9).

They are also fitted with an adjustable "run

on" timer (1 to 30 minutes), and the unit will

continue to operate for the set period after

initiation by the movement detector.

= To set the temporisation, turn the

potentiometer on the printed board (fig.7):

- To reduce the "run on" time, turn

anticlockwise (min. 1 minute)

- Toincrease the "run on" time, turn clockwise

(max: 30 minutes).

The extractor fan only requires periodical

cleaning using a cloth lightly impregnated

with a soft detergent.

We recommend you not to try to dismantle or

remove any other parts than those mentioned

as any tampering would automatically cancel

the S&P guarantee. If you detect any fault,

contact your S&Pdealer.

S&P reserves the right to alter specifications

without notice

Operation

SILENT-100 CDZ (this version is only

available as SILENT-100)

The CE norm and our commitment to future

generations require us to recycle waste

material; please deposit all remaining

elements of the packaging into containers

for recycling, and carry the equipment that

has been replaced to the nearest waste

center or your dealer.

User instruction

This instruction is available under

http://www.solerpalau.com or contact your

National Soler y Palau contact.

List see http://www.solerpalau.com.

This appliance can be used by children aged

from 8 years and above and persons with

reduced physical, sensory or mental

capabilities or lack of experience and

knowledge if they have been given

supervision or instruction concerning use of

the appliance in a safe way and understand

the hazards involved. Children shall not play

with the appliance. Cleaning and user

maintenance shall not be made by children

without supervision.
