6. Starting Web Management

The following shows how to start up the Web Management of the Managed

Switch. Note the Managed Switch is congured through an Ethernet connection.

Please make sure the manager PC must be set on the same IPsubnetaddress.

For example, the default IP address of the Managed Switch is 192.168.0.100,

then the manager PC should be set at 192.168.0.x (where x is a number

between1and254,except100),andthedefaultsubnetmaskis255.255.255.0.

PC / Workstation

with

IE Browser

RJ-45/UTP-Cable

IP Address:

192.168.0.x

IP Address:

192.168.0.100

Managed Switch

Figure 6-1: IP Management Diagram

Logging in the Managed Switch

1. Use Firefox, Internet Explorer 8.0 or above Web browser. Enter IP address

http://192.168.0.100(thefactorydefaultIPaddressortheonethatyouhave

justchangedinconsole)toaccesstheWebinterface.
