3-1
Chapter 3: Chassis Components
Chapter 3
Chassis Components
3-1 Overview
This chapter describes the most common components included with your chassis.
Some components listed may not be included or compatible with your particular
chassis model. For more information, see the installation instructions detailed later
in this manual.
3-2 Components
Chassis
The chassis includes one slim DVD dummy cover, and two 3.5" xed hard drives.
For the latest shipping lists, visit our Web site at: http://www.supermicro.com.
Fans
The SC523 chassis accepts two system fans. System fans for the SC523 chassis
are powered from the serverboard. These fans are 80 x 38 mm and are powered
by 4-pin connectors.
Mounting Rails
The SC523 can be placed in a rack for secure storage and use. To set up your
rack, follow the step-by-step instructions included in this manual.
Power Supply
Each SC523 chassis model includes a high-efciency power supply rated at 410
or 520 Watts. In the unlikely event your power supply fails, replacement is simple
and can be done without tools.
