![Supermicro cse-523l-520b [51/52] Appendix b](/views2/1190283/page51/bg33.png)
B-1
Appendix B: Power Supply Specications
Appendix B
SC523 Power Supply Specications
This appendix lists power supply specications for your chassis system.
SC523L-410B
410W (Redundant)
MFR Part # PWS-0061
Rated DC Voltage
Voltage Range: -36 to -72V
Nominal Voltage: -.48V
Max Input Current: 18A @ -48V
9.5 - 4.5 Amp
DC Output 5V + 3.3V ≤ 160W
+5 35.0 Amp
+5V standby 3.0 Amp
+12V 32.0 Amp
-12V
0.5 Amp
+3.3V
20.0 Amp
SC523L-520B
520W (Redundant)
MFR Part # PWS-521-1H
AC Voltage
100 to 240V
50-60 Hz
7-3 Amp
+5 20 Amp
+5V standby 3 Amp
+12V 39 Amp
-12V
0.5 Amp
+3.3V
16 Amp
