Chapter 1
Introduction
1-1 Overview
The SuperServer 6027R-N3RF/WRF is a high-end server comprised of two main
subsystems: the SC825TQ-R740WB 2U server chassis and the X9DRW-3F/iF dual
processor serverboard. Please refer to our web site for information on operating
systems that have been certifi ed for use with the system (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have been
included with the SuperServer 6027R-N3RF/WRF, as listed below:
• Two (2) 2U Passive CPU Heatsinks (SNK-P0048PS)
• One (1) SC825/826/216/213 DP X9,X8 PC Air shroud (MCP-310-29001-0N)
• Two (2) 2U passive CPU heat sinks (SNK-P0048PS)
• Three (3) 80x80x38-mm Chassis Middle Fans (FAN-0126L4)
• One (1) 76-cm round 16-to-16-pin Ribbon Front Panel Control Cable
(CBL-0017L)
• SAS/SATA Accessories
One (1) SAS/SATA backplane (BPN-SAS-825TQ-O-P)
Two (2) 30AWG 64/54/44/34-cm SAS connection cables (CBL-0188L-02) (for
SuperServer 6027R-N3RF only)
Two (2) 30AWG 76/66/54/45-cm AOC SAS connection cables (CBL-0343L-01)
(for SuperServer 6027R-WRF only)
Eight (8) hot-swap 3.5" hard-disk drive trays (MCP-220-00075-0B)
• One (1) Riser Card (RSC-R2UW-4E8-O-P)
• One (1) Rackmount kit (MCP-290-00053-0N)
Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety information:
http://www.supermicro.com/about/policies/safety_information.cfm
• If you have any questions, please contact our support team at:
support@supermicro.com
