1-2
SUPERSERVER 6027R-N3RF/WRF User's Manual
1-2 Serverboard Features
At the heart of the SuperServer 6027R-N3RF/WRF lies the X9DRW-3F/iF, a dual
processor serverboard based on the Intel PCH 606/602 chipset. Below are the main
features of the X9DRW-3F/iF. (See Figure 1-1 for a block diagram of the chipset).
Processors
The X9DRW-3F/iF supports single or dual E5-2600 Series processors in
Socket R LGA2011 type sockets. Please refer to our web site for a complete listing
of supported processors (www.supermicro.com).
Memory
The X9DRW-3F/iF has sixteen (16) single/dual/tri/quad channel 240-pin DIMM
sockets that can support up to 512 GB of DDR3 1600/1333/1066/800 MHz speed
registered ECC RDIMM/LRDIMM SDRAM in two-channel memory bus. Memory
sizes of 1GB, 2GB, 4GB, 8GB, 16GB and 32GB @ 1.35V/1.5V voltages are
supported. Please refer to Chapter 5 for installing memory.
Note: LRDIMM (Reduced Load) memory supports only 1333/1066/800 MHz speed
memory.
Serial ATA
An on-chip SATA controller is integrated into both the X9DRW-3F/iF serverboards
to provide a six-port SATA subsystem (two SATA 3.0 and four SATA 2.0 ports),
which is RAID 0, 1, 5 and 10 (Windows SATA) or RAID 0, 1 and 10 (LINUX and
SAS) supported. The SATA drives are hot-swappable units. The X9DRW-3F
serverboard uses the PCH C606 SAS/SATA controller, while the X9DRW-iF use
the PCH C602 SATA only controller.
Note: You must have RAID set up to enable the hot-swap capability of the SATA
drives. Documentation on RAID setup guidelines can be found on our web site.
SAS (6027R-N3RF Server Only)
For the X9DRW-3F serverboard only, a SAS controller is integrated into the
PCH C606 chipset to provide an eight port SAS (Serial Attached SCSI) subsystem,
which is RAID 0, 1, and 10 supported. (Optional RAID 5 support is available with
the RAIDKEY installed.) The SAS drives are hot-swappable units.
Note: The operating system you use must have RAID support to enable the
hotswap capability and RAID function of the SAS drives.
