X10DAi/X10DAC/X10DAX Motherboard User's Manual
1-3 Special Features
Recovery from AC Power Loss
The Basic I/O System (BIOS) provides a setting that determines how the system will
respond when AC power is lost and then restored to the system. You can choose for
the system to remain powered off (in which case you must press the power switch
to turn it back on), or for it to automatically return to the power-on state. See the
Advanced BIOS Setup section for this setting. The default setting is Last State.
1-4 System Health Monitoring
This motherboard has an onboard Hardware Monitor Controller that supports sys-
tem health monitoring, and it will scan the following onboard voltages continuously:
1.05V, 1.2V, 1.5V, +3.3V, 3.3VSB, +5V, +5V Standby, +12V, chipset, memory, and
battery voltages. Once a voltage becomes unstable, a warning is given, or an error
message is sent to the screen. The user can adjust the voltage thresholds to dene
the sensitivity of the voltage monitor.
Fan Status Monitor with Firmware Control
The onboard Hardware Monitor Controller can check the RPM status of a cooling
fan.
Environmental Temperature Control
The Hardware Monitor Controller monitors the CPU temperature in real time and
will turn on the thermal control fan whenever the CPU temperature exceeds a
user-dened threshold. Once it detects that the CPU temperature is too high, it will
automatically turn on the thermal fan control to prevent the CPU from overheating.
The onboard chassis thermal circuitry can monitor the overall system temperature
and alert the user when the chassis temperature is too high.
Note: To avoid possible system overheating, please be sure to provide
adequate airow to your system.
System Resource Alert
This feature is available when used with SuperDoctor® 5. SuperDoctor 5 is
used to notify the user of certain system events. For example, you can congure
SuperDoctor 5 to provide you with warnings when the system/CPU temperatures,
CPU voltages and fan speeds go beyond a predened range.
