SC826 Chassis Manual
1-2
SC826E26-R1200UB
12x SAS/SATA
4x FF (1x UIO),
3x LP
1200W Redundant
(Gold Level)
SC826A-R1200LPB
12x SAS/SATA 7x LP
1200W Redundant
(Gold Level)
SC826A-R1200UB
12x SAS/SATA
4x FF (1x UIO),
3x LP
1200W Redundant
(Gold Level)
S826BA-920LPB
12x SAS/SATA +2 opt. 7x LP
920W Redundant
(Platinum Level)
SC826BA-R920UB
12x SAS/SATA +2 opt. 4x FH, 2x LP
920W Redundant
(Platinum Level)
SC826BA-R920WB
12x SAS/SATA +2 opt. 4x FH, 3x LP
920W Redundant
(Platinum Level)
SC826BE26-R920LPB
12x SAS/SATA +2 opt., dual
expander SAS2 backplane
7x LP
920W Redundant
(Platinum Level)
SC826BE26-R920UB
12x SAS/SATA +2 opt., dual
expander SAS2 backplane
4x FH, 2x LP
920W Redundant
(Platinum Level)
SC826BE26-R920WB
12x SAS/SATA +2 opt., dual
expander SAS2 backplane
4X FH, 3x LP
920W Redundant
(Platinum Level)
SC826BE16-R920LPB
12x SAS/SATA +2 opt., single
expander SAS2 backplane
7x LP
920W Redundant
(Platinum Level)
SC826BE16-R920UB
12x SAS/SATA +2 opt., single
expander SAS2 backplane
4X FH, 2x LP
920W Redundant
(Platinum Level)
SC826BE16-R920WB
12x SAS/SATA +2 opt., single
expander SAS2 backplane
4x FH, 3x LP
920W Redundant
(Platinum Level)
SC826TQ-R800LP(V)
(B)
12x SAS/SATA 7x LP 800W Redundant
SC826TQ-R800UB
12x SAS/SATA
4x FF (1x UIO),
3x LP
800W Redundant
SC826TQ-R500LPB
12x SAS/SATA 7x LP
500W Redundant
(Platinum Level)
SC826E16-R500LPB
12x SAS/SATA 7x LP
500W Redundant
(Platinum Level)
Legend:
LP: Low prole
FF: Full-height, full-length
FH: Full-height, half-length
